88 ° Gigun Radius tẹ pẹlu ilẹkun Wiwọle

88° Gigun Radius tẹ pẹlu Ilẹkun Wiwọle Aworan Ifihan
  • 88 ° Gigun Radius tẹ pẹlu ilẹkun Wiwọle
  • 88 ° Gigun Radius tẹ pẹlu ilẹkun Wiwọle
  • 88 ° Gigun Radius tẹ pẹlu ilẹkun Wiwọle

Apejuwe kukuru:

SML EN877 CAST IRON PIP FITTINGS fun ile idominugere

88 ° Gigun Radius tẹ pẹlu ilẹkun Wiwọle

Standard: BS EN877 / DIN 19522 / ISO6594

Ohun elo: simẹnti grẹy irin ISO185

Aso: Epoxy Resini Kun & Powder iposii

Awọ: pupa tabi grẹy

Siṣamisi: OEM tabi M-Tub tabi ni awọn ibeere awọn onibara

Ibi abinibi: China

Ohun elo: Omi idominugere

Agbara fifẹ min.150Mpa

O pọju brinell líle HB260

Idaabobo awọ inu si sokiri iyọ: o kere ju 350h, awọn wakati 700 ti o wọpọ.resistance si omi apanirun: o kere ju awọn ọjọ 30 ni 23 ℃.

resistance kemikali lati PH2 si PH12 o kere ju awọn ọjọ 30 ni 23 ℃.

resistance si gigun kẹkẹ otutu: 1500 yiyi laarin si 15-93 ℃.


Ṣe igbasilẹ bi PDF

Alaye ọja

ọja Tags

Iru ọja:

88 ° Gigun Radius tẹ pẹlu ilẹkun Wiwọle

QQ截图20220323162838
Opin Inu (D) Radius(R) Oju afọmọ X1 X3 X4
mm mm
100 200 100 217.1 233.1 233.1
100 600 100 495 620 620
150 600 150 522.4 630 630
200 600 200 550 640 640
150 300 150 314 340 340
200 400 200 410.8 447 447
250 600 260 582 650 650
300 600 310 610 660 660

45 ° Tẹ kukuru pẹlu ilẹkun iwọle

QQ截图20220323162852
DIA. X
mm mm
50 75
75 95
100 112
100 153
150 148
200 180
250 220
300 260



88 ° Tẹ Kukuru pẹlu ilẹkun iwọle

QQ截图20220323162901
DIA. X
mm mm
50 75
75 95
100 112
100 153
150 148
200 180
250 220
300 260

45° Ẹka Nikan pẹlu ilẹkun Wiwọle

QQ截图20220323162909
DIA. X1 X2 X3 L
mm mm mm mm mm
50 x 50 51 135 135 186
75 x50 50 140 140 190
75 x 75 66 160 160 226
100 x 50 35 165 165 200
100 x 75 55 175 180 230
100 x 100 70 205 205 275
150 x 75 58 228 212 286
150 x 100 55 240 240 295
150 x 150 90 265 265 355
200 x 100 65 285 260 350
200 x 150 75 300 300 375
200 x 200 115 340 340 455
250 x 250 130 430 430 560
300 x 200 82 428 440 510
300 x 300 155 505 505 660

Ẹka Nikan 88 ° pẹlu ilẹkun Wiwọle

QQ截图20220323162934
DIA. X1 X2 X3 L
mm mm mm mm mm
50 x 50 79 81 66 145
75 x50 95 90 86 181
75 x 75 130 130 90 220
100 x 100 170 150 104 274
150 x 50 150 130 140 290
150 x 100 140 151 140 280
150 x 150 210 190 140 350
200 x 150 185 185 165 350
200 x 200 194 201 181 375
250 x 150 212 224 224 436
250 x 200 212 233 224 436
250 x 250 244 241 224 468
300 x 200 265 263 250 515
300 x 250 265 270 250 515
300 x 300 277 278 263 540

Ijẹrisi:

iwo877
